RAM-VP-TTMF12-101U-D RAM® 12" Upper Flange Pole with Double Ball Mount
RAM-VP-TTMF12-101U-D RAM® 12" Upper Flange Pole with Double Ball Mount
Couldn't load pickup availability
Share
- Description
The RAM® 12" Upper Flange Pole with Double Ball Mount (RAM-VP-TTMF12-101U-D) consists of a 12" upper male Tele-Pole™ with a connection point for the 3-part ball and socket system. The 2.5" round ball features the universal 4-hole AMPS hole pattern to connect any RAM® device holder or GDS® Dock™. The Tele-Pole™ can be easily adjusted by turning the knob at the top of the post. Once the knob has been tightened, the Tele-Pole™ becomes a rigid support for connecting devices or cradles. The Tele-Pole™ will connect to any RAM® vehicle base with a welded female Tele-Pole™.
Features
- 12" pole installs onto any RAM® vehicle base with a welded female Tele-Pole™
- Ball and socket mounting system offers shock and vibration damping
- Compatible with any RAM® holders or GDS® docks with a 4 hole AMPS pattern
- Backed by a lifetime warranty
Specifications
Hardware included: Assembly Hardware
Product dimensions: Overall Height: 26.85"
Socket to socket length: 8"
Hole pattern: 4-Hole AMPS: 1.181" x 1.496", 3-Hole 120-Degree: 1.812" Diameter
Plate size: 2.5" Diameter
Ball size: C Size (1.5")
Weight capacity: Standard Use: 4 lbs, Heavy-Duty Use: 3 lbs
Materials: Powder coated steel, Marine-grade aluminum
Packaging type: Poly Bag
Weight: 5.27 lb
