The RAP-B-407-UN10U consists of the Tough-Wedge vehicle seat wedge base, composite double socket
arm, and X-Grip universal large phone holder. This mount fits conveniently in the gap between your
vehicle's passenger seat and center console, creating a temporary but also very rugged mounting
platform for your phone. The mount is designed with a RAM 1" diameter patented rubber ball and
socket system that has adjustment points at both ends of the double socket arm. With the turn of a
knob you can set your phone to the perfect viewing and operating angle. The X-Grip is compatible
with handheld devices that will fit the dimensions listed below. It is important to verify the
dimensions of your handheld device with a case/sleeve/skin when determining the overall size.
HARDWARE INCLUDED
Assembly Hardware
(1) Optional Tether
(1) Glue Tube for Rubber Caps
HOLDER DIMENSIONS
Width Range: 1.75" - 4.5"
Depth Range: .875" max
WEDGE DIMENSIONS
Length: 13.25"
Height: 8.25"
Thickness: 1"
SOCKET-TO-SOCKET LENGTH
3"
BALL/SOCKET SIZE
B Size (1")
WEIGHT CAPACITY
2 lbs
MATERIALS
High strength composite
Stainless steel
PACKAGING TYPE
Poly Bag
ADDITIONAL INFORMATION
arm, and X-Grip universal large phone holder. This mount fits conveniently in the gap between your
vehicle's passenger seat and center console, creating a temporary but also very rugged mounting
platform for your phone. The mount is designed with a RAM 1" diameter patented rubber ball and
socket system that has adjustment points at both ends of the double socket arm. With the turn of a
knob you can set your phone to the perfect viewing and operating angle. The X-Grip is compatible
with handheld devices that will fit the dimensions listed below. It is important to verify the
dimensions of your handheld device with a case/sleeve/skin when determining the overall size.
HARDWARE INCLUDED
Assembly Hardware
(1) Optional Tether
(1) Glue Tube for Rubber Caps
HOLDER DIMENSIONS
Width Range: 1.75" - 4.5"
Depth Range: .875" max
WEDGE DIMENSIONS
Length: 13.25"
Height: 8.25"
Thickness: 1"
SOCKET-TO-SOCKET LENGTH
3"
BALL/SOCKET SIZE
B Size (1")
WEIGHT CAPACITY
2 lbs
MATERIALS
High strength composite
Stainless steel
PACKAGING TYPE
Poly Bag
ADDITIONAL INFORMATION
Purchase Includes:
- (QTY. 1) Optional Tether Included
Cradle Dimensions:
- Minimum Width = 1.75" (Minimum Height = 5.5")
- Maximum Width = 4.5" (Minimum Height = 3.25")
- Depth = 0.875"
- Material:High Strength Composite &
Stainless Steel - Ball Size:B Size 1" Rubber Ball
- Note:The "U" in the part number reflects product packaged in poly bag. RAM highly recommends using the provided Tether for all open cockpit applications while using this product.
RAM-HOL-UN10BU
RAP-407BU
RAP-B-201U
RAP-B-238U
