RAM Single Socket Arm with 1/2" NPT Threaded
RAM Single Socket Arm with 1/2" NPT Threaded
Regular price
$49.49 USD
Regular price
Sale price
$49.49 USD
We have new inventory arriving weekly, If you see low or no inventory it may change tomorrow. Please call us at 1.800.789.0087 or email us at sales@custommounts.com for current inventory status.
UPC:
793442020018
Mfg Part #:
RAM-200-1U
Availability:
Out Of Stock
Part Number:
RAM-200-1U
Quantity
Couldn't load pickup availability
Share
- Description
- Additional Info
- Components
The RAM-200-1U includes a single socket that will accommodate 1.5" balls and a 1/2" NPT Female
thread. This part will connect to 1/2" NPT Male threads, including RAM-PA82XX rigid arms.
BALL/SOCKET SIZE
C Size (1.5")
WEIGHT CAPACITY
4 lbs
MATERIALS
Marine-grade aluminum
PACKAGING TYPE
Poly Bag
ADDITIONAL INFORMATION
Note: NPT (National Pipe Thread) is a standard used in joining pipes and fittings that have a
tapered thread. As a general rule, the NPT inch size is the inside diameter of the threaded pipe and
is known as the NPS (Nominal Pipe Size). The outer diameter (OD) of the pipe is shown in the table
below. NPT Size (NPS) Pipe Outer Dia. (OD) Threads per inch 1/4" 0.540" 18
1/2" 0.840" 14 1" 1.315" 11.5
WEIGHT
0.63 lbs.
thread. This part will connect to 1/2" NPT Male threads, including RAM-PA82XX rigid arms.
BALL/SOCKET SIZE
C Size (1.5")
WEIGHT CAPACITY
4 lbs
MATERIALS
Marine-grade aluminum
PACKAGING TYPE
Poly Bag
ADDITIONAL INFORMATION
Note: NPT (National Pipe Thread) is a standard used in joining pipes and fittings that have a
tapered thread. As a general rule, the NPT inch size is the inside diameter of the threaded pipe and
is known as the NPS (Nominal Pipe Size). The outer diameter (OD) of the pipe is shown in the table
below. NPT Size (NPS) Pipe Outer Dia. (OD) Threads per inch 1/4" 0.540" 18
1/2" 0.840" 14 1" 1.315" 11.5
WEIGHT
0.63 lbs.
- Material:Powder Coated Marine Grade Aluminum
- Ball Size:C Size 1.5" Rubber Ball
- Note:The "U" in the part number reflects product packaged in poly bag.
- NPT Thread and Pipe Sizing:NPT (National Pipe Thread) is a standard used in joining pipes and fittings that have a tapered thread. As a general rule, the NPT inch size is the inside diameter of the threaded pipe and is known as the NPS (Nominal Pipe Size). The outer diameter (OD) of the pipe is shown in the table below.
- Weight:0.63 lbs.
|
