GDS Modular 10-30V Hardwire C

The GDS Modular Hardwire Charger with USB Type-C cable is the ideal solution for providing power to any GDS vehicle solution. With the quick disconnect feature, easily connect any USB Type A charging cable. When it comes time to upgrade, avoid any rewiring by simply unplugging the power connector and attaching the new charger components. Compatible with any 5V device with a current requirement of 2.5A or less.

Packaging Type
Poly Bag

Input Voltage
10V - 30V DC

Output Voltage
5-9VDC

Output Current
2.5A max

Input Connector
USB Type-C

Input Cable Length
1.2 Meters including 2 Pole Flat Marine Connector

Output Cable Length
.2 Meter

Operating Temperature
-10°C to +70°C

Storage Temperature
-40°C to +70°C

Compliance
Over Voltage Protection Short Circuit Protection Reverse Polarity Protection RoHS Compliance WEEE Compliance SAE J-1113-5 Load Dump (Transient Voltage) Moisture Resistant

Certifications
CE Certification e-Mark Certification RCM Certification FCC Certification

Weight
0.43 lbs.

Warranty Status
3 year warranty
